ABB PM511V08 3BSE011180R1
| Category | Specific Content |
|---|---|
| Product Name | ABB PM511V08 Processor Module (Part Number: 3BSE011180R1) |
| Product Description | The ABB PM511V08 3BSE011180R1 is a dedicated high-performance processor module tailored for the ABB Advant Controller 450 and Advant OCS/Advant Master industrial control systems. As the core computing component of industrial automation setups, it undertakes key tasks such as real-time data processing, complex control logic execution, and communication coordination with field devices and upper-level systems. It is designed with a Future Bus + board featuring 32-bit address and data lines, and integrates hardware support for redundant processors to enhance system stability. The modular structure with a PCMCIA slot facilitates easy replacement of flash memory cards for program updates and function expansion. Equipped with LED status indicators, it enables quick diagnostics of module operating conditions. This module is widely applied in power generation, oil and gas, chemical engineering, and smart grid fields, delivering reliable performance in harsh industrial environments with its resistance to shock and vibration. |
| Product Parameters | 1. Processor & Memory Parameters: Adopts a 25 MHz Motorola 68040 processor; comes with 8 MB dynamic RAM with error-checking and correction (ECC) function. It is also equipped with boot PROM and SRAM for system initialization, along with dual independent instruction and data MMUs and two separate 4 KB caches (one for data and one for instructions).
2. Power Parameters: Supports dual voltage input. The typical current for 5V DC is 4900 mA, with a maximum of 6000 mA; the typical current for 24V DC is 200 mA, with a maximum of 280 mA. The typical power loss in the form of heat is 25 W. 3. Communication Parameters: Supports multiple communication modes including RS-232, Ethernet, and CAN bus. It is also compatible with industrial protocols such as Modbus RTU and Profibus DP, and features a distributed arbitration mechanism with Future Bus + compelled transfers. 4. Expansion Parameters: Equipped with an S100 I/O interface for bus extension and a PCMCIA slot for inserting flash memory cards or function expansion cards to meet customized application requirements. |
| Specifications | 1. Physical Specifications: Measures 274.5 mm × 270 mm × 27 mm and weighs approximately 0.76 kg. Its compact design allows for easy installation in standard industrial control cabinets.
 2. Environmental Specifications: The operating temperature range is -25°C to +55°C, and the storage temperature range can reach -40°C to +85°C. It can withstand 30 g of impact and 5 g of vibration, which can adapt to the harsh working conditions of industrial sites. 3. Reliability Specifications: It supports redundant processor logic for backup operation, which effectively prevents system downtime due to single-module failures. The modular design allows for convenient maintenance, and the status LED indicators facilitate quick fault location. 4. Compliance Specifications: Classified as small equipment under WEEE standards with no external dimension exceeding 50 cm. Its customs tariff number is 85389091, and it complies with relevant industrial operation and safety standards for stable application in various industrial scenarios. |
