ABB CI854AK01
This module is engineered to support multiple communication protocols, providing great flexibility in connecting to different types of fieldbus systems. It can handle protocols such as Profibus DP, enabling reliable communication with a wide range of Profibus – compatible devices like sensors, actuators, and remote I/O units. With its advanced communication processing capabilities, the CI854AK01 ensures fast and accurate transmission of data, which is essential for real – time monitoring and control of industrial operations.
The CI854AK01 features a robust and reliable design, built to withstand harsh industrial environments. It has excellent electrical isolation and high electromagnetic compatibility (EMC), protecting it from electrical noise, voltage fluctuations, and electromagnetic interference commonly found in industrial settings. The module also incorporates comprehensive self – diagnostic functions that continuously monitor its internal components, communication status, and power supply. In case of any faults or abnormal conditions, it immediately generates detailed diagnostic information and alarms, allowing maintenance personnel to quickly identify and resolve issues, minimizing system downtime.
Installation and integration of the CI854AK01 are straightforward. It can be easily inserted into the I/O rack of the AC 800M controller system, and its configuration can be carried out using ABB’s dedicated software tools. This simplicity in setup and operation makes it a popular choice for engineers aiming to build efficient and reliable industrial automation systems.
Product Parameters
- Communication Parameters
- Supported Protocols: Profibus DP (V0), with optional support for additional protocols in some configurations
- Data Transmission Rate: Supports all standard Profibus baud rates from 9.6 kbps to 12 Mbps, automatically adapting to the network – set rate
- Number of Slave Devices: Can communicate with up to 125 Profibus DP slave devices
- Communication Interfaces: 1 Profibus DP interface with M12 connectors for reliable fieldbus connection
- Electrical Parameters
- Power Supply: 24 VDC ± 20%, derived from the I/O rack power system
- Power Consumption: Approximately 3 W, ensuring energy – efficient operation within the industrial control system
- Electrical Isolation: Isolation voltage of 500 VAC between channels and system, enhancing protection against electrical surges
- Operating Environment Parameters
- Operating Temperature: – 20°C to + 60°C, suitable for a wide range of industrial temperature conditions
- Storage Temperature: – 40°C to + 85°C
- Relative Humidity: 5% – 95% non – condensing, enabling stable operation in different humidity environments
- Data Processing Parameters
- Data Buffering: Built – in data buffers to ensure smooth data flow and prevent data loss during high – speed communication
- Update Time: Fast data update times, typically within milliseconds, for real – time control applications
Product Specifications
- Physical Specifications
- Dimensions: Length × Width × Height = 100 mm × 36 mm × 175 mm
- Weight: Approximately 0.2 kg, lightweight for easy handling and installation
- Mounting Method: Designed for standard DIN – rail mounting within the I/O rack of the AC 800M controller system
