ABB 5SHY4045L0006
Product Name
ABB 5SHY4045L0006 High-Voltage IGCT Power Semiconductor Module (Integrated Gate-Commutated Thyristor, 4500 V Class)
Product Description
The ABB 5SHY4045L0006 (internal ID: 3BHB030310R0001) is a high-power IGCT module engineered for medium/high-voltage industrial power conversion and drives, such as MV drives, traction converters, STATCOMs, and HVDC applications. It combines the low on-state losses of a thyristor with gate-commutated turn-off capability, enabling high efficiency and reliable operation at elevated voltages and currents. The module features rugged packaging with integrated thermal management, overcurrent/overtemperature protection, and compatibility with ABB’s gate driver units (e.g., GVC736 series) for seamless system integration. Its design is optimized for harsh industrial environments, supporting critical applications in power generation, petrochemicals, metallurgy, and rail traction where uptime and power density are paramount.
Product Parameters
| Parameter Category | Specific Parameter |
|---|---|
| Ordering Code/Internal ID | 5SHY4045L0006; 3BHB030310R0001 |
| Device Technology | IGCT (Integrated Gate-Commutated Thyristor) |
| Rated Blocking Voltage (VRRM/VDRM) | 4500 V (typical for 5SHY4045 series) |
| Rated RMS Current (IT(RMS)) | 45 A (typical for this variant; confirm with datasheet) |
| On-State Voltage (VT) | ≤ 3.5 V (typical at rated current, junction temp. Tj=25 °C) |
| Gate Control Voltage | Typically ±15 V DC (compatible with ABB standard gate drivers) |
| Maximum Junction Temperature (Tj(max)) | +125 °C (continuous operation) |
| Operating Temperature Range (Ambient) | -25 °C to +70 °C (cabinet-mounted, forced cooling) |
| Storage Temperature Range | -40 °C to +85 °C |
| Protection Class | IP20 (module housing; system-level IP depends on enclosure) |
| Cooling Requirement | Forced air or liquid cooling (per thermal design) |
Specifications
Mechanical Specifications
- Dimensions (Typical): ~145 mm × 245 mm × 32 mm (L×W×H; cabinet-mounted module)
- Weight: ~3.7 kg (approximate, incl. baseplate and terminals)
- Mounting: Bolted to heatsink/thermal baseplate; torque-controlled fasteners
- Housing: Flame-retardant plastic (UL94 V-0)+metal shielding for EMC
