  1. Product Name

    ABB 5SHY3545L0010 IGCT Power Module (Internal Part Number: 3BHB013088R0001)

  2. Product Description

    The ABB 5SHY3545L0010, with the matching internal part number 3BHB013088R0001, is a high-performance IGCT power module that combines the advantages of Gate Turn – Off Thyristors (GTO) and Insulated Gate Bipolar Transistors (IGBT). It adopts advanced semiconductor technology and a compact structural design, which achieves excellent performance in terms of high power density, fast switching speed and low energy loss, effectively reducing heat generation during operation and improving the overall energy conversion efficiency of the system.

This module is specifically developed for high-voltage
ABB 5SHY4045L0006 and high-current power electronic scenarios. It is widely applied in industrial automation motor drive systems, renewable energy equipment like wind turbines and solar inverters, power transmission and distribution networks, as well as power control systems in heavy industries such as mining and metallurgy. Its triple – shielded architecture and galvanic isolation technology enable it to maintain stable operation even in environments with electromagnetic interference up to 150V/m. Additionally, it is equipped with multiple self – diagnostic functions and protection mechanisms such as overload, overheating and short – circuit protection, which can timely respond to abnormal working conditions and extend the module’s service life while ensuring the safety of the whole system.3. Product Parameters & Specifications
Parameter Category Specific Specifications
Electrical Parameters Maximum voltage: 1200V; Maximum current: 2500A; Gate triggering voltage range: 4V – 20V; Rated input voltage: 220V AC ±10%; Operating frequency range: 47 – 63Hz; Signal accuracy: ±0.02% FS; Output frequency: 50kHz.
Mechanical Specifications Dimensions: 120mm × 80mm × 60mm; Weight: Approximately 1kg; Installation method: Suitable for standard industrial mounting and compatible with integrated installation in power control cabinets.
Environmental Specifications Operating temperature range: -40°C to 125°C; Storage temperature: -40°C to 150°C (recommended); Operating humidity: 5% – 95% (non – condensing); Electromagnetic interference tolerance: 150V/m; Protection class: IP67.
Certification & Functional Specifications Certifications: CE, ROHS, UL, IEC 61000 – 6 – 4; Core functions: Fast switching control, adaptive noise cancellation, real – time self – diagnosis; Compatibility: Can be seamlessly integrated with various industrial control systems and supports quick matching with power electronic equipment in multiple fields.
