ABB XVC768117 3BHB007211R117
The ABB XVC768117 3BHB007211R117 module, also known as the XVC768 Series 40A Single Phase Solid State Relay, is a solid-state relay module used to switch AC loads in industrial control systems.
Product description
The XVC768117 3BHB007211R117 module is a single-phase solid-state relay with the following features:
Rated input voltage: 230VAC or 400VAC
Rated output voltage: 230VAC or 400VAC
Rated output current: 40A
Input control signal: 3-32VDC
Photoelectric isolation: there is photoelectric isolation between input and output to prevent interference and noise
Zero cross switch: Loads can be switched at zero cross points to reduce arcing and interference
LED indicator: Has an LED indicator to indicate the status of the relay
The XVC768117 3BHB007211R117 module can be used in a variety of industrial control applications, including:
Motor control
Heating control
Lighting control
Valve control
Relay control
Product parameter
Parameter value
Rated input voltage 230VAC or 400VAC
Rated output voltage 230VAC or 400VAC
Rated output current 40A
Input control signal 3-32VDC
Control power 125mW
Leakage current 1mA
Switching time 0.5ms
Disconnect time 0.1ms
Operating temperature range -40°C to +80°C
