ABB KUC755AE105 3BHB005243R0105

Product NameABB KUC755AE105 3BHB005243R0105 Industrial Automation Drive Power Supply Module
Product DescriptionThe ABB KUC755AE105 3BHB005243R0105 is a high-performance drive power module under ABB’s industrial automation series. Its core function is to provide stable and reliable power supply for various industrial automation equipment and drive devices. It can adjust voltage and current flexibly to meet the power demands of different working conditions of the connected equipment.

This module supports multiple control modes, including speed control, torque control, and position control, which makes it well – suited for scenarios requiring high-precision control of motor operation. It adopts high-quality components and optimized circuit design, endowing it with the advantages of high reliability and long service life. Moreover, it is equipped with multiple protection functions such as over-current, over-voltage, short – circuit, and over-heat protection. These functions can quickly respond to abnormal electrical conditions, thus effectively avoiding damage to the module itself and the connected equipment. It can operate stably in harsh industrial environments and is widely used in fields like manufacturing production lines, energy management systems, water treatment equipment, and heavy industries such as petroleum and metallurgy.
Product Parameters

Parameter	Details
Manufacturer	ABB
Model	KUC755AE105 3BHB005243R0105
Input Voltage	380V AC – 480V AC
Output Voltage	DC 24V
Rated Output Power	75kW
Rated Output Current	150A
Frequency Range	0.5Hz – 800Hz
Rated Rotational Speed	0 – 1500rpm
Operating Temperature Range	-20°C to +60°C
Protection Rating	IP20

Specifications

Specification Item Details

Dimensions 600mm × 450mm × 250mm

Weight Approximately 60kg

Installation Method DIN rail mounting

Compatibility
