3ASC25H214 DATX130
Product Name
3ASC25H214 DATX130 is a ABB Industrial Automation Control & Communication Module (also referred to as ABB DATX130 Process Interface Module, Distributed Control System (DCS) Signal Processing Module), a core hardware component designed for ABB industrial automation and DCS systems.
2. Product Description
The 3ASC25H214 DATX130 module is a high-performance industrial-grade control and communication component developed by ABB, specifically tailored for distributed control systems and industrial process automation scenarios. Its core functions include real-time signal acquisition, data processing, logic operation, and bidirectional communication between the central controller and field devices.
Adopting a modular design, the module supports flexible integration with ABB DCS systems (such as Advant OCS and 800xA) and is compatible with various field sensors, actuators, and intelligent instruments. It features robust anti-electromagnetic interference (EMI) capabilities and industrial-grade environmental adaptability, ensuring stable operation in harsh industrial environments with temperature fluctuations, dust, and vibration.
Equipped with standard industrial communication protocols and signal processing circuits, the DATX130 module enables high-speed and reliable data transmission, supporting both analog and digital signal processing. It is widely used in process control fields such as petrochemicals, power generation, metallurgy, and water treatment, serving as a key link between the control layer and field layer in industrial automation systems to ensure precise monitoring and control of production processes.
3. Product Parameters
| Parameter Category | Specific Specifications |
|---|---|
| Product Type | Industrial Automation Control & Communication Module, DCS Signal Processing Module |
| Manufacturer | ABB |
| Compatible Systems | ABB Advant OCS, 800xA DCS Systems |
| Input Signal Type | Analog Input (4-20mA, 0-10V), Digital Input (Dry Contact, NPN/PNP) |
| Output Signal Type | Analog Output (4-20mA, 0-10V), Digital Output (Relay, Transistor) |
| Number of Channels | 8 Analog Inputs, 8 Digital Inputs, 4 Analog Outputs, 4 Digital Outputs (Standard Configuration) |
| Communication Protocol | Profibus DP, Modbus RTU, ABB proprietary communication protocol |
| Power Supply | 24V DC ±10%, Redundant Power Input Supported |
| Operating Temperature | -20℃ to +60℃ |
| Storage Temperature | -40℃ to +85℃ |
| Relative Humidity | 5% – 95% RH (Non-condensing) |
| Protection Class | IP20 (For Cabinet Mounting) |
| Power Consumption | Maximum 15W |
| Weight | Approximately 0.8kg |
| Dimensions (W×H×D) | 140mm × 210mm × 80mm (Standard Modular Size) |
| Certifications | CE, UL, CSA, IEC 61010 |
4. Specifications
(1) Physical Specifications
- Mechanical Structure: Compact modular design, compatible with standard TS35 DIN rail mounting or ABB DCS cabinet slot mounting, facilitating integration with other automation modules.
- Housing Material: Flame-retardant industrial plastic shell with electromagnetic shielding coating, enhancing anti-interference performance and mechanical durability.
