369-HI-R-0-0-0-0-E
| Item | Details |
|---|---|
| Product Name | 369-HI-R-0-0-0-0-E GE Multilin Motor Management Relay Module |
| Product Description | The 369-HI-R-0-0-0-0-E is a high-performance motor management relay module developed by GE Multilin, dedicated to comprehensive protection, monitoring and control of medium and low-voltage motors in industrial applications. It integrates multiple protection functions including overcurrent, overload, phase loss, undervoltage, overvoltage and earth fault protection, and provides real-time monitoring of motor operating parameters such as current, voltage and temperature. The module supports flexible configuration via local or remote interfaces, and can seamlessly communicate with PLC/DCS systems to realize centralized motor management. With its robust design, it is suitable for harsh industrial environments such as power plants, petrochemical plants and manufacturing facilities, effectively reducing motor downtime and improving operational reliability. |
| Product Parameters | 1. Rated Voltage: 208/240/480/600 V AC (phase-to-phase, configurable)
2. Current Input: 5 A AC (standard CT input, compatible with 1 A AC via setting) 3. Protection Functions: Overload, thermal overload, phase unbalance, phase loss, overcurrent, earth fault, undervoltage, overvoltage 4. Measurement Accuracy: Current measurement ±0.5% of reading; voltage measurement ±0.5% of reading  5. Operating Temperature: -25°C ~ +70°C (operating); -40°C ~ +85°C (storage) 6. Power Supply: 85–265 V AC / 90–300 V DC (wide voltage range, redundant power supply optional) 7. Communication Interface: RS485 (Modbus RTU protocol, standard configuration) 8. Trip Output: 2 × Form C relay contacts (rated 5 A @ 250 V AC, 10 A @ 30 V DC) 9. Response Time: ≤ 20 ms (for instantaneous overcurrent protection) |
| Specifications | 1. Housing Material: NEMA 4X/IP66-rated die-cast aluminum housing (front panel); metal mounting base
2. Mounting Type: Flush panel mounting, DIN rail mounting (optional with adapter) 3. Dimensions: 145 mm × 115 mm × 85 mm (L×W×H, main unit, subject to actual product) 4. Protection Grade: IP66 (front panel); IP20 (terminals, when installed in cabinet) |
