3500/32 125712-01大卡
. Product Name
3500/32 125712-01 is a Bently Nevada 3500 Series 4-Channel Relay Output Module (also referred to as Bently Nevada 3500/32 Alarm & Trip Relay Module, Industrial Machinery Protection System Relay Card), a core safety and alarm output component designed for Bently Nevada 3500 Machinery Protection System (MPS).
2. Product Description
The 3500/32 125712-01 module is an industrial-grade relay output module developed by Bently Nevada (a Baker Hughes company, part of GE Vernova) for the 3500 Series Machinery Protection System. As a critical interface between the 3500 monitoring system and field safety devices, its primary function is to receive alarm/trip signals from 3500 system monitors (e.g., vibration, temperature, speed monitors) and output relay contacts to trigger protective actions—such as emergency shutdown (ESD), equipment tripping, or audible/visual alarms.
Featuring 4 independent, configurable relay channels, the module supports flexible alarm/trip logic customization to meet specific machinery protection requirements. It adopts a rugged industrial design with enhanced electromagnetic interference (EMI) resistance and wide environmental adaptability, ensuring reliable operation in harsh industrial environments (e.g., power plants, refineries, turbomachinery installations) with temperature fluctuations, vibration, and electrical noise.
Seamlessly integrating with the 3500 Series system chassis and monitoring modules, the 3500/32 125712-01 complies with global industrial safety standards, providing fail-safe operation to protect critical rotating machinery (turbines, compressors, motors, generators) from damage due to abnormal operating conditions. It is widely used in power generation, oil and gas, petrochemical, and manufacturing industries.
3. Product Parameters
| Parameter Category | Specific Specifications |
|---|---|
| Product Type | Bently Nevada 3500 Series 4-Channel Relay Output Module |
| Manufacturer | Bently Nevada (Baker Hughes, GE Vernova) |
| Compatible Systems | Bently Nevada 3500 Machinery Protection System (3500/15 Chassis, 3500/40 Monitoring Modules, etc.) |
| Number of Channels | 4 Independent Relay Channels |
| Relay Type | Form C (SPDT: Single Pole Double Throw) |
| Contact Rating | 250V AC / 30V DC, 5A Resistive Load; 250V AC, 2A Inductive Load (cosφ=0.4) |
| Contact Life | ≥100,000 Operations (At Rated Load) |
| Output Logic | Configurable (Normally Energized/Normally De-Energized for Alarm/Trip) |
| Response Time | ≤10ms (Relay Activation/Deactivation) |
| Isolation Level | Channel-to-Channel: ≥500Vrms; Channel-to-System: ≥1000Vrms |
| Power Supply | Powered by 3500 System Chassis (5V DC from Backplane) |
| Operating Temperature | 0℃ to +65℃ (32°F to +149°F) |
| Storage Temperature | -40℃ to +85℃ (-40°F to +185°F) |
| Relative Humidity | 5% – 95% RH (Non-condensing, IEC 60068-2-3) |
| Protection Class | IP20 (Designed for Cabinet Mounting) |
| Dimensions (W×H×D) | 160mm × 100mm × 220mm (6.30″ × 3.94″ × 8.66″) |
| Weight | Approximately 0.5kg (1.1 lbs) |
| Certifications | CE, UL, CSA, ATEX, IECEx |
| Diagnostic Capabilities | Relay Contact Feedback Monitoring, Module Self-Diagnosis, Backplane Communication Check |
4. Specifications
(1) Physical Specifications
- Mechanical Design: Modular form factor compatible with Bently Nevada 3500 Series 19-inch rack-mount chassis (3500/15 10-slot chassis, 3500/16 16-slot chassis), featuring a compact design for space-efficient integration.
- Housing & Material: Flame-retardant industrial-grade plastic shell (UL 94 V-0 rating) with electromagnetic shielding, providing mechanical durability and resistance to EMI/RFI interference.
- Interface & Indicators: Front-panel LED indicators for each channel (Channel Active, Relay Fault) and module status (Power, Communication), enabling real-time visual monitoring; backplane connector for seamless integration with the 3500 system chassis.
(2) Functional Specifications
-
Relay Output Performance
- 4 independent SPDT (Form C) relays support both alarm notification and trip control functions, with configurable logic (normally energized/normally de-energized) to adapt to different safety requirements.
- High-contact rating (5A @ 250V AC) enables direct control of field devices such as contactors, solenoid valves, and alarm horns without additional interface modules.
- Fast response time (≤10ms) ensures timely activation of protective actions when abnormal machinery conditions are detected.
-
System Integration & Configuration
- Seamlessly integrates with the 3500 Machinery Protection System via the chassis backplane, receiving trigger signals from 3500 monitoring modules (vibration, speed, temperature, position monitors).
- Configurable via Bently Nevada 3500 Rack Configuration Software (Version 5.0 and above), allowing users to set relay logic, fault detection parameters, and diagnostic functions.
- Supports redundant configuration (dual modules) for critical applications, enhancing system reliability and eliminating single points of failure.
-
Reliability & Diagnostic Functions
- Built-in relay contact feedback monitoring detects contact wear or failure, transmitting fault data to the 3500 system for alarm and troubleshooting.
- Module self-diagnosis checks power supply, backplane communication, and internal circuitry, ensuring early detection of hardware anomalies.
- Complies with IEC 61010-1 and IEC 61326-2-4 standards for electrical safety and EMC performance, ensuring stable operation in industrial environments.
(3) Application Specifications
- Applicable Systems: Bently Nevada 3500 Machinery Protection System, suitable for protecting critical rotating machinery in safety-critical applications.
- Industry Applications: Power generation (thermal, nuclear, hydro), oil and gas (upstream, midstream, downstream), petrochemical, chemical processing, and manufacturing.
- Typical Use Cases: Turbine Protection Systems, Compressor Alarm/Trip Control, Motor Vibration Monitoring & Shutdown, Generator Fault Protection, and Pump Machinery Safety Interlocks.
