Product Name
Allen – Bradley 1394C – SJT05 – D SERCOS Interface System Module
Product Description
The Allen – Bradley 1394C – SJT05 – D module is a servo controller module that is part of the Allen – Bradley Bulletin 1394/1394C servo controller product line1. It is designed for industrial motion control systems that support multiple axes1. This modular, multi – axis motion control drive system module has a rated power of 5 kW and can be used as an integrated motion control and drive system (GMC)1. It provides direct – line connection (without transformer) for 360 – volt and 480 – volt three – phase input power supplies1.
The 1394C – SJT05 – D module offers a digital servo drive system with a fiber – optic digital network interface1. It can be used as a speed or torque control system and can be quickly commissioned through the Allen – Bradley SERCOS interface module1. It also provides a SCANport interface as a standard function1. Additionally, the module is equipped with highly – integrated surface – mount circuitry and DSP – assisted processing, and has improved ground termination on the SERCOS and axis modules1. The system has digitally – adjustable speed and current loop compensation functions to adapt to various system inertias1.
Product Parameters
- Power Supply
- AC Input: 380/460 VAC 3 – phase 50/60 Hz 6.5 A, 24 Vrms 1 – phase DC/50/60 Hz 15 A max.
- DC Output: 530/680 V 1 – phase 7.5 A, 4/5 kW.
- Communication
- It has a SERCOS interface for high – speed digital communication with other devices in the motion control system.
Control Functions
- It supports speed control, torque control, and position control modes. It also has functions such as digital adjustment of speed and current loop compensation, and can perform various motion control algorithms.
Product Specifications
- Axes Configuration1: It can be configured with a maximum of four – axis modules, and each module interfaces with a motor.
- Physical Dimensions: Specific dimensions are usually not provided in the common product information. But generally, it is designed to fit into standard industrial control cabinets and has a size that is suitable for modular installation.
- Weight: The weight information is not typically emphasized in the product description, but it is lightweight enough to be easily installed and integrated into the system.
- Environmental Requirements: It is designed to operate in a typical industrial environment, with an operating temperature range of usually – 20°C to + 55°C and a relative humidity of 5% – 95% non – condensing. However, it is recommended to refer to the official manual for the exact environmental specifications.
