10350-00104
Product Name
10350-00104 is a Woodward Industrial Control System I/O Module (also referred to as Woodward 10350-00104 Digital Input/Output Module, Turbomachinery Automation I/O Interface Module), a core signal processing and interface component designed for Woodward industrial control systems, primarily used for turbomachinery (turbines, generators) and industrial process control applications.
2. Product Description
The 10350-00104 module is an industrial-grade I/O (Input/Output) module developed by Woodward (a global leader in energy control solutions), engineered to serve as a critical interface between Woodward control systems (e.g., MicroNet TMR, ProTech GT) and field devices. Its core functions include real-time acquisition of digital/analog signals from sensors, switches, and transducers, as well as output of control signals to actuators, valves, and alarm devices—enabling seamless data exchange between the control layer and field layer.
Adopting a rugged industrial design with enhanced electromagnetic interference (EMI) resistance and wide environmental adaptability, the module ensures stable operation in harsh industrial environments (e.g., power plants, refineries, petrochemical facilities) characterized by temperature fluctuations, vibration, and electrical noise. It supports flexible configuration of input/output channels to meet specific application requirements and integrates seamlessly with Woodward’s control software for parameter setting, status monitoring, and fault diagnosis.
Widely used in turbomachinery control, power generation, oil and gas, and process industries, the 10350-00104 module plays a key role in ensuring precise control, reliable protection, and efficient operation of critical industrial equipment.
3. Product Parameters
| Parameter Category | Specific Specifications |
|---|---|
| Product Type | Woodward Industrial Control System I/O Module (Digital I/O + Analog I/O Combo) |
| Manufacturer | Woodward Inc. |
| Compatible Systems | Woodward MicroNet TMR, ProTech GT, and Woodward Industrial Control Platforms |
| Input Channel Configuration | 8 Digital Inputs (DI) + 4 Analog Inputs (AI) |
| Output Channel Configuration | 4 Digital Outputs (DO) + 2 Analog Outputs (AO) |
| Digital Input Type | Dry Contact / NPN/PNP Open Collector, 24V DC Nominal |
| Analog Input Type | 4-20mA Current Loop, 0-10V DC Voltage (Configurable), 16-bit Resolution |
| Digital Output Type | Relay Output (SPDT, Form C), 250V AC / 30V DC, 5A Resistive Load |
| Analog Output Type | 4-20mA Current Loop, 0-10V DC Voltage (Configurable), 16-bit Resolution |
| Input/Output Isolation | Channel-to-Channel: ≥500Vrms; Channel-to-System: ≥1000Vrms |
| Communication Interface | Woodward Proprietary Backplane Bus, RS485 (Modbus RTU Optional) |
| Power Supply | 24V DC ±10%, Redundant Power Input Supported |
| Power Consumption | Typical: 12W; Maximum: 18W |
| Operating Temperature | -40℃ to +70℃ (-40°F to +158°F) |
| Storage Temperature | -40℃ to +85℃ (-40°F to +185°F) |
| Relative Humidity | 5% – 95% RH (Non-condensing, IEC 60068-2-3) |
| Protection Class | IP20 (Designed for Cabinet Mounting) |
| Dimensions (W×H×D) | 145mm × 200mm × 75mm (5.71″ × 7.87″ × 2.95″) |
| Weight | Approximately 0.7kg (1.54 lbs) |
| Certifications | CE, UL, CSA, ATEX, IECEx, ISO 9001 |
| Diagnostic Capabilities | Channel Fault Detection (Open/Short Circuit), Module Self-Diagnosis, Power Supply Monitoring |
4. Specifications
(1) Physical Specifications
- Mechanical Design: Modular form factor compatible with Woodward standard control system racks and TS35 DIN rail mounting, featuring a compact design for space-efficient integration in industrial control cabinets. Reinforced mounting clips ensure stability in high-vibration environments.
- Housing & Material: Flame-retardant industrial-grade plastic shell (UL 94 V-0 rating) with electromagnetic shielding coating, providing mechanical durability and resistance to EMI/RFI interference. The module is equipped with dust-proof terminal covers for unused channels.
- Interface & Indicators: Front-panel LED indicators for power status (PWR), module health (OK), channel activation (per-channel DI/DO/AO/AI LEDs), and fault alarms (FAULT); spring-loaded terminal blocks for secure and tool-less wiring, simplifying installation and maintenance.
(2) Functional Specifications
- Signal Processing Performance
- 8 digital inputs support dry contact, NPN, and PNP signals, enabling compatibility with a wide range of field switches, sensors, and interlock devices; 4 analog inputs (16-bit resolution) accurately measure process parameters such as pressure, temperature, and flow (4-20mA/0-10V).
- 4 digital relay outputs (SPDT) can directly drive contactors, solenoid valves, and alarm d
