GFD233A103 3BH022294R0103

Product Description

• The GFD233A103 3BHE022294R0103 module is a high – performance controller module designed as a general – purpose controller, which can be used in a variety of applications, including process control, machine control, and automated production lines3.
• It is a real – time modular system that combines network functions and is designed for a wide range of control and monitoring applications, such as power networks, power generation, transmission, and distribution systems. The solution is highly scalable and easy to implement, deploy, and maintain. The system can grow with future needs and support virtualized environments to reduce hardware costs.
• The module integrates the core functions of excitation control, including voltage and current regulation, power factor control, protection functions, etc. It adopts advanced control algorithms to ensure the stable operation of generators under various operating conditions and optimize their performance. Moreover, it supports a variety of configuration options to meet the needs of different generators and applications. Users can easily adjust control parameters and protection functions through software settings or hardware jumpers2.

Product Parameters

• Processor: It is usually equipped with a high – performance pro
•
• cessor, such as the PM861 RISC 32 – bit real – time multi – tasking microprocessor, which can achieve fast response and high – efficiency control13.
• Memory: 16 MB RAM with error detection and correction, backed up by a battery and including battery voltage monitoring; EPROM, serial, 16 Kbit1.
• Communication Interfaces: It is equipped with 2 Ethernet interfaces and 2 RS232C interfaces, and supports Modbus, Profibus – DP and other communication protocols, which are convenient for data exchange with monitoring systems, energy management systems, etc12.
• Expansion Capabilities: It supports the expansion of 12 field – bus modules, and can connect up to 12 S800 I/O modules and 192 S800 I/O points through the electrical ModuleBus mode. It can also connect seven S800 I/O clusters through the optical fiber ModuleBus connector on the card. In addition, the system can expand more I/O clusters through the Profibus – DP bus1.
• Task Processing: It can handle up to 16 tasks, with a minimum task cycle of 1 ms, and the resolution of SOE (Sequence of Events) is less than 1 ms1.
• Protection Functions: It has comprehensive protection functions, such as over – current protection, under – voltage protection, over – temperature protection, etc., to ensure the safe operation of the generator2.

Specifications

• Installation Method: DIN – rail mounting. Each module consists of a detachable unit and a base that are interconnected. The base realizes the external connection between modules, including power supply and communication1.
