BANNER LS4RLQ

LS4RLQ four-way 24V DC relay output module

Product Description:

Four-way 24V DC relay output module for BANNER 8000 series controllers
With four relays, it can be used to control motors, valves, etc
Product parameters:

Working voltage: 24V DC
Output voltage: 24V DC
Output current: 10A
Operating temperature range: -40°C to +70°C
Storage temperature range: -40°C to +85°C
Specifications:

Dimensions: 72 x 27 x 75mm
Weight: 0.1kg
Connection mode: DIN connection
Protection class: IP65
Applications:

Motor control
Valve control
Other applications requiring four 24V DC relay outputs
Advantages:

Simple operation
Job stability
High protection level
Wiring mode standard
How to use:

Install LS4RLQ module on DIN rail.
Connect the power supply to the input end of the module.
Connect the load to the output of the module.
